YEW AIK AJ 00360 3403 Tacho HiTester - 50 to 200mm

YEW AIK AJ 00360 3403 Tacho HiTester - 50 to 200mm

This YEW AIK AJ 00360 3403 Tacho HiTester is used for measuring rotation speed and linear velocity. With a range of 50 to 200mm, achieve precise and accurate readings for various applications. Ideal for industrial use, this Tacho HiTester is a reliable tool for professionals.

The 3403 Tacho HiTester is used for accurate measurement of motor speeds and mechanical acceleration. Its digital display and adjustable speed range make it ideal for a variety of industries, from automation engineering to manufacturing. The tool also features stable and reliable measurement capabilities for accurate and reliable results.

3403 Tacho HiTester

Precise rotation speed meter

• High-resolution, high-precision

• MAX.,MIN.,TOTAL,PERIOD measurement

• Auto-ranging from 30 to 100,000 rpm

• Double performance, contact and non contact type

• Recorder out put (3404)

Measurement

Method: Visible light reflectance

Display: 41 /2 digits (5 digit display for 20,000 counts or higher ,lowest digit fixed to zero), LCD

Detection distance: 50 to 200mm

Reflected light

detected check: Buzzer and LED

Analog output: 1000mV DC f.s.(3404 only) Output accuracy ±1% rdg. ±1mV, output resistance 1k1

Power supply: R6P(AA) x 4, continuous use approx. 17h(3403), approx. 16h(3404) or AC adapter (6V, 300mA)

Dimension: 62W x 180H x 38Dmm•260g

Accessories: 3403 : 9211 Reflective tape(1 sheet), carrying case 3404 : 9211(1 sheet), 9094 output cord (1.5m), carrying case

- Refer to Chart Size Image for product specification
